Transmitter

class Transmitter(seed=None, selected_transmit_ports=None, carrier_frequency=None)

Bases: Generic[TransmissionType], RandomNode, MixingOperator

Operator transmitting over a device.

Parameters:

• seed (int | None) – Random seed used to initialize the pseudo-random number generator.

• selected_transmit_ports (Sequence[int] | None) – Indices of antenna ports selected for transmission from the operated Device's antenna array. If not specified, all available ports will be considered.

• carrier_frequency (float | None) – Central frequency of the mixed signal in radio-frequency transmission band. If not specified, the operated device’s default carrier frequency will be assumed during signal processing.

abstract _transmit(state, duration)

Generate information to be transmitted.

Subroutine of the public transmit method that performs the pipeline-specific transmit-processing and consolidates the generated information into a single hermespy.core.device.Transmission object.

Parameters:

• state (TransmitState) – State of the device at the time of transmission.

• duration (float) – Duration of the transmitted signal in seconds. If not specified, the duration of a single frame will be assumed.

Return type:

TypeVar(TransmissionType, bound= Transmission)

Returns: Information to be transmitted.

add_transmit_callback(callback)

Add a callback to be called after processing the transmit DSP algorithm.

Parameters:

callback (Callable[[TypeVar(TransmissionType, bound= Transmission)], None]) – Function to be called after processing the transmit DSP algorithm. The transmit output is passed as the only argument.

Return type:

Hook[TypeVar(TransmissionType, bound= Transmission)]

Returns: Hook to be used for removal.

notify_transmit_callbacks(transmission)

Notify the registered callbacks about the generated transmission.

Parameters:

transmission (TypeVar(TransmissionType, bound= Transmission)) – Transmission to be passed to the callbacks.

Return type:

None

serialize(process)

Serialize this object’s state.

Objects cannot be serialized directly, instead a Factory must be instructed to carry out the serialization process.

Parameters:

process (SerializationProcess) – The current stage of the serialization process. This object is generated by the Factory and provides an interface to serialization methods supporting multiple backends.

Return type:

None

transmit(state, duration=0.0, notify=True)

Transmit a signal.

Registers the signal samples to be transmitted by the underlying device.

Wrapper around the abstract _transmit method.

Parameters:

• state (DeviceState) – State of the device at the time of transmission. If not specified, the device’s current state will be queried by calling hermespy.core.device.Device.state().

• duration (float) – Duration of the transmitted signal. If not specified, i.e. zero, the duration will be inferred by the transmitter.

• notify (bool) – Notify the transmitter’s callbacks about the generated transmission.

Return type:

TypeVar(TransmissionType, bound= Transmission)

Returns:

Information generated while transmitting over this operator.

Raises:

FloatingError – If the transmitter is currently considered floating.

abstract property power: float

Expected power of the transmitted signal in Watts.

Note

Applies only to the signal-carrying parts of the transmission, silent parts shuch as guard intervals should not be considered.

property selected_transmit_ports: Sequence[int] | None

Indices of antenna ports selected for transmission from the operated Device's antenna array.

If None, all available transmit ports will be considered.
